ELITE 20 PRO FB4 IP65

Name: ELITE 20 PRO FB4 IP65
Brand: Kvant Lasers, s.r.o.
Price: 5782.00 EUR
Availability: InStock

5,782.00€ ex. TAX

Step into high-powered performance with the ELITE 20 PRO FB4 IP65 — an all-weather, high-output laser light show projector built for large indoor and medium outdoor spaces and events.
The ELITE 20 PRO FB4 IP65 offers full control via DMX, ArtNET, and Ethernet (from a PC) all through the built-in FB4.

The ELITE PRO FB4 IP65 series is designed for lighting professionals who need dependable performance in a wide range of event environments. Featuring a rugged IP65 weatherproof housing, these laser systems are built to handle demanding conditions while delivering consistent, high-quality output. Ideal for large indoor venues such as mega clubs, as well as outdoor events including stadiums, arenas, and festivals, the ELITE PRO FB4 IP65 offers the flexibility, durability, and reliability required for professional lighting applications.

Quantity:

ELITE 20 PRO FB4 IP65

5,782.00€ ex. TAX

Unity Lasers Elite Pro FB4 IP65 laser show system projecting multicolored beams across a dark stage setup

ELITE PRO FB4 SERIES VIDEO

ELITE 20 PRO FB4 IP65 specification table

Product Name:

Unity ELITE 20 PRO FB4 (IP65)

Type Of Laser:

Full-colour, Semiconductor diode laser system

Guaranteed Optical Output:

>20W

Suitable For:

Lighting professionals: arena sized venues (up to 30,000 people), outdoor shows. Beam show, text, graphic, and mapping capable

Scanning System:

35,000 points per second @ 8°

Scan Angle:

45°

Safety:

Fully complies with the latest EN 60825-1 and FDA regulations

Weight:

15.5kg

Package Includes:

Laser projector w/ FB4 DMX, IP65 housing, protective case, Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power cable (1.5M/4.5ft), interlock (* service dongle if outside US), keys, outdoor RJ45 connectors, manual, quickstart guide, variance card

R | G | B [mW]:

6,400 | 6,400 | 8,000

Beam Size [mm]:

6 x 6

Beam Divergence:

<1.2mrad [Full Angle]

Modulation:

Analog 100kHz

Power Requirements:

100-240V/50Hz

Consumption:

Max. 400W

Operation Temperature:

(-10°C) - 45°C

Ingress Rating:

IP65

System Features:

All the adjustments, such as power output of each color, X & Y axes invert, X & Y size and position, safety, etc., are managed digitally by the FB4 control system. Ethernet in/out, power in/out, DMX in/out, Estop in/out

Laser Safety Features:

Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate

Notice:

*Due to Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output

Dimensions [mm]:

Depth: 385 | Width: 338 | Height: 191
